HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring

HT-02/HT-02D is a thermal Imaging Camera that combines the functions of surface temperature measurement and real-time thermal imaging the traditional thermal imaging Camera shall measure each component one by one but this instrument does not need to. Therefore, it helps to save our customer’s time. Even the potential problems can be clearly displayed on the color screen which helps customers quickly locate the central point to measure cursor and temperature.

Features:
1. Infrared thermal imager that can blend the visible and infrared images.
2. Resolution of infrared image/visible image: 3600/1024(HT-02D) pixels/0.3 megapixels.
3. This infrared imaging device is professional, precise, and efficient.
4. For car engine overhaul, transformer room line maintenance, air conditioner repair, etc.
5. Our infrared thermal imager can turn thermal image into a visional image, quickly find out the problem area.

Specifications:
Display: 2.4 inch wide viewing angle high-resolution color screen
Resolution: HT-02(60*60),HT-02D(32*32)
Resolution of visible image: 0.3 megapixels.
Total Pixel: 3600
Field angle / Shortest focal distance: 20× 20/0.5m
Thermal Sensitivity: 0.15 degrees
Measuring Mode: Thermopile
Range of Temperature measurement: -20 degrees to 300 degrees (-4 Fahrenheit to 572 Fahrenheit)
Measuring Accuracy: ±2% or ±2 degrees (±4Fahrenheit )
Wavelength Range: 8-14um
Emissivity: 0.1-1.0 Adjustable
The image capturing Frequency: 6HZ
Focus distance: Fixed focal distance
Color Palette: Iron red,rainbow,rainbow high contrast,gray scale(white glow) and gray scale(black glow)
Vision Option: 5 kinds of full infrared to the full visual, mixing visible and infrared.
Memory card: Mini SD card(4G)
File Format: BMP
Set Control: Unit Adjustment/Language/Date Time Format/automatic shut down
Battery Type: 4 * No5 AA batteries (Not Included)
Battery Life: 6 Hours
Auto Power-off Time: 12 Minutes
Authentication: CE(EN61326-1:2006)
Operating Temperature: -5 degrees to 40 degrees (23 Fahrenheit to 104 Fahrenheit )
Storage Temperature: -20 degrees to 50 degrees (-4 Fahrenheit to 122 Fahrenheit )
Relative Humidity: 10%RH to 80%RH
Dimension of product (L*W*H) : 21.2 * 9.5 * 6.2cm
Item Weight: 320g
Warranty period: 2 years

Package Lists:
1 * Thermal Infrared Imager
1 * SD Card(4G)
1 * User Manual
1 * Drop Resistance Rope
1 * Protection bag

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 6

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 7HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 8HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 9

3: HT-18(220*160)

Shining Points:

—3.2” full color screen, allows for detailed showing of infrared generated images;
—220×160 resolution and 0.3 million pixels visible image resolution, high definition of images;
—-20~300°/-4°~572° temperature measurement range, 2.5° accuracy for better operation;
—5 kinds of the palette for choice: rainbow, iron red, cold color, black & white and white & black;
—Automatic setting: 5 mintues/20 minutes/ not power off automatically;
—Built-in 4GB SD card for storage, the pics can be also transferred to television, computer or other devices for checking;
—Wide application at medical, fire-fighting, archaeology, traffic, farming, electronic manufacture, and other fields;
—Seperate button for a specific function, which is quite easy for you to turn it on or off, delete or check pictures;
—Mini and portable for 90×105×223mm size and 289g weight, attached pouch allows for more convenient carrying;
—Ergonomic handle, which can be used and held comfortably.

Specification:

Specification:

Display screen: 3.2” full-color screen
Infrared image resolution: 220×160
Visible image resolution: 0.3 million pixel
Thermal sensitivity: 0.07°
Temperature measurement range: -20~300°(-4°~572°)
Measurement precision: ±2.5° or ±2.5%
Wavelength coverage: 8-14um
Field angle/shortest focus length: 27°×35°/0.5m
Emissivity: Adjustable from 0.1 to 10.0
Focus mode: Fixed
Image capture frequency: 8Hz
View option: full infrared and full vision Visible image with 25% step length
Storage medium: built-in 4G
Image format: JPG
Power supply: built-in chargeable 18650 batteries
USB: Micro USB2.0
Automatic power-off time: 5 mintues/20 minutes/ not power off automatically
Size: 90×105×223mm
Weight: 289g
Work temperature: 0° to 50°
Storage temperature: -40° to 80°
Humidity: <85RH
Package Includes:
1 x infrared temperature detector
1 x cable
1 x user manual
1 x carry pouch
1 x carry pouch strap
1 x cardboard package box
HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 10

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 11

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 12

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 13

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 14

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 15

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 16

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 17

4 HT-A1 Thermal Camera(220*160)

This product is an inferred camera that integrates surface temperature measurement and real-time thermal image. The traditional inferred thermometer needs to measure every component one by one while it is not necessary for infrared imaging camera, thus saving time. The potential problems may be displayed on the color display screen clearly. Moreover, the central point measurement cursor is used to locate quickly and accurately to measure the temperature of the target object.

Features:
In order to increase differentiation, the product is provided with a visible light camera. The thermal images and visible images are stored in the device and can be read through USB or stored in a computer to generate a report or for print.
The product can be used in fields of medical treatment, fire fighting, archaeology, traffic, agriculture, geology, energy, smelting, electronic manufacture, etc and is the ideal selection for an electrician, maintenance personnel and technicians, and can be used to find the problem area quickly.
3.2″ full angle TFT display screen can get the information you need more clearly.
The buttons on the machine body are clearer and easier to operate.
LED lighting lamp on the back can fill light in dark environments.
Equipped with a hanging rope for easy carrying.

Specification:
Material: plastic+rubber
Color: black+yellow
Display screen: 3.2″ full angle TFT display screen
Infrared image resolution: 220 * 160
Visible image resolution: 640 * 480 (300000 pixel)
Field angle/shortest focus length: 35°*26°/4.0mm
Thermal sensitivity: 0.07℃
Temperature measurement range: -20℃ to 300℃ (-4°F to 572°F)
Measurement accuracy: ±2%/±2℃
Emissivity: adjustable from 0.01 to 1.0
The frame rate of thermal images: 9Hz
Wavelength coverage: 8-14μm
Focus mode: fixed
Color palette: rainbow, iron oxide red, cold color, black & white, white & black
View option: the integration of thermal image with 25% step length and visible image
Storage medium: built-in 3G
File format: JPG
USB: Micro USB 2.0
Battery: 1 * lithium battery, 3.7V, 1800mAh (included)
Automatic power-off time: selectable: 5 minutes/20 minutes/ not power off automatically
Working temperature: 0℃-45℃
Storage temperature: -20℃-60℃
Relative humidiity: <85%RH
Item size: 140 * 80 * 28mm / 5.5 * 3.1 * 1.1in
Item weight: 204g / 7.2ounce
Package size: 175 * 100 * 60mm / 6.9 * 3.9 * 2.4in
Package weight: 434g / 1.0lb

Package List:
1 * Thermal Imager
1 * USB Data Cable
1 * Switching Adapter
1 * Hanging Rope
1 * User Manual

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 18

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 19

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 20

5.HT-175 Univeral Infrared Thermal Imaging Camera 1024P 32×32 IR Image Resolution Digital Thermal Imager

Features:
1. Portable design and simple operation.
2. I could find the problem area quickly.
3. With a display screen. Obtains different images and converts it into standard video format and display.
4. Have 2 suitable selection of color palette displays the details of the target objective better.
5. An ideal selection for electrician and maintenance personnel and technicians

Description:
1. Form high resolution image.
2. Available when Batteries are installed (Buttery not included).
3. Measurement mode: Infrared focal plane temperature measurement

Specifications:
Display screen: 2.0 color screen
Infrared image resolution: 32×32
Pixel: 1024
Measurement range: -20~300°
Measurement precision: ±2%/±2°
Wavelength coverage: 8-11.5um
Focusing mode: fixed
Color palette: iron oxide red and white glow
Power supply: 3×AAA alkaline battery (Buttery not included)
Working temperature: 0-50°
Storage temperature: -20°~50°
Size: 165*58*64mm
Package Size: 191*97*76mm

Package included:
1 x Infrared Thermal Camera
1 x Instruction Manual

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 21

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 22

HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring 23

Specification: HT-02 Handheld Thermal Imaging Camera With Digital Display For Temperature Measuring

Brand Name Hti
Theory Infrared Thermometer
Model Number HT-175/HT-02D/HT-02/HT-A1/HT-18
Max Measuring Temperature 120°C & Above
Display Type Digital
Usage Industrial
Power Type Charger
Style Handheld
Display Size 2.0 - 3.9 Inches
